M2TECH Joplin MkIII ADC/phono
€2,970.00
Tax included
Convertitore A/D operante fino a 384kHz e 32 bit con interfaccia USB 2.0 Audio class compatibile.
Our privacy policy
Our Privacy Policy explains our principles when it comes to the collection, processing, and storage of your information. This policy specifically explains how we employ cookies, as well as the options you have to control them.
-
1 What are cookies?
Cookies are small pieces of data, stored in text files that are stored on your computer or other device when websites are loaded in a browser. They are widely used to "remember" you and your preferences, either for a single visit or for multiple repeat visits
-
2 How we use cookies
We use cookies for a number of different purposes. Some cookies are necessary for technical reasons; some enable a personalized experience for both visitors and registered users; and some allow the display of advertising from selected third party networks.
-
3 Controlling Cookies
Visitors may wish to restrict the use of cookies or completely prevent them from being set. If you disable cookies, please be aware that some of the features of our service may not function correctly
-
4 Information We Collect
We only collect information about you if we have a reason to do so-for example, to provide our services, to communicate with you, or to make our services better.
We are committed to maintaining the trust and confidence of our website visitors. We do not collect, sell, rent or trade email lists or any data with other companies and businesses. Have a look at our Privacy Policy page to read detail information on when and why we collect your personal information, how we use it, the limited conditions under which we may disclose it to others and how we keep it secure.
We may change Cookies and Privacy policy from time to time. This policy is effective from 24th May 2018.
nputs: |
analog single-ended (RCA) SPDIF (RCA) |
Outputs: |
SPDIF (RCA) AESEBU (XLR) optical (Toslink) USB 2.0 high speed I2S |
Sample frequencies: |
PCM 44.1kHz to 384kHz |
Sample frequencies on I2S output: |
PCM 44.1kHz to 768kHz, DSD 64x to 256x |
PCM resolution: |
16 bits to 32 bits |
Signal-to-Noise Ratio: |
122dBA (gain: 0dB) |
THD+N: |
0.0003% (gain: 0dB) |
Input sensitivity: |
2.5Vrms (gain: 0dB) 1.4mVrms (gain: 65dB) |
Analog gain: |
0dB; 10dB to 65dB |
Digital gain: |
average 6-8dB with each phono curve (easily interfaces with MC cartridges with output voltage down to 4-500uV with minimum loss of resolution and signal-to-noise ratio) |
Analog input impedance: |
10 Ohms to 50 kOhms || 100pF |
Low-pass filter: |
5kHz 10kHz disabled |
High-pass filter: |
50Hz 16Hz disabled |
MPX filter: |
-60dB @ 19kHz |
I2S output modes: |
off bypass (same sampling frequency as menu setting) PCM x1 (44.1/48) PCM x2 (88.2/96) PCM x4 (176.4/192) PCM x8 (352.8/384) PCM x16 (705.6/768) DSD 64x DSD 128x DSD 256x |
Supply voltage: |
15VDC |
Power Consumption: |
4W (operational) 1W (standby) |
Size: |
200x200x50mm (wxdxh) |
Weight: |
net 2kg (including ancillaries) gross 2.5kg |
